ESD二极管NUP2105L特性
400 watts peak pulse power (tp = 8/20μs)
Response Time is Typically < 1 ns
Protects one bidirectional line or two unidirectional lines
Working Voltages: 24V
Low clamping voltages
JEDEC SOT-23 package
IEC 61000-4-2 (ESD) ±30kV (air), ±30kV (contact)
IEC 61000-4-4 (EFT) 40A (5/50ns)
IEC 61000-4-5 (Lightning) 8A (8/20μs)Molding compound flammability rating:
UL 94V-0
Marking : Marking Code
Packaging : Tape and Reel per EIA 481
RoHS Compliant
ESD二极管NUP2105L应用
Automotive Networks
Control & Monitoring Systems
Portable Electronics
Set-Top Box
Servers, Notebook, and Desktop PC
Wireless Bus Protection
型号 | 图片 | 封装 | VBR.MIN(V) | Ppp(W) | CJ(PF) | IR(nA) | VRWM(V) | IPP(A) | VC(V) | 下载 |
---|---|---|---|---|---|---|---|---|---|---|
SOT-23 |
26.7 |
400 |
25 |
200 |
24 |
8 |
50 |
