产品特性
• 玻璃钝化芯片
• 在10/1000μ波形重复率（占空比）：0.01%下，峰值脉冲功率可达400w
• 高可靠性应用，符合汽车级AEC -Q101认证标准
• 低漏电流
• 单、双向单元
• 优良的钳位能力
• 快速的响应时间
• 通过无铅认证，符合ROHS
机械参数
• 方法：模制塑料
• 环氧树脂：UL 94V-0阻燃剂
• 引线：可焊性按MIL-STD-750，方法2026可焊
• 极性：除双极性外有色带的一端为阴极
• 安装位置：任何
| 型号 | 图片 | 封装 | VBR.MIN(V) | VBR.MAX(V) | IT(mA) | IR(μA) | VRWM(V) | IPP(A) | VC(V) | 下载 |
|---|---|---|---|---|---|---|---|---|---|---|
|
SMA/DO-214AC |
11.10 |
12.30 |
1 |
5 |
10.0 |
23.53 |
17.0 |
|
|
|
SMA/DO-214AC |
12.20 |
13.50 |
1 |
1 |
11.0 |
21.98 |
18.2 |
|
|
|
SMA/DO-214AC |
13.30 |
14.70 |
1 |
1 |
12.0 |
20.10 |
19.9 |
|
|
|
SMA/DO-214AC |
14.40 |
15.90 |
1 |
1 |
13.0 |
18.60 |
21.5 |
|
|
|
SMA/DO-214AC |
15.60 |
17.20 |
1 |
1 |
14.0 |
17.24 |
23.2 |
|
|
|
SMA/DO-214AC |
16.70 |
18.50 |
1 |
1 |
15.0 |
16.39 |
24.4 |
|
|
|
SMA/DO-214AC |
17.80 |
19.70 |
1 |
1 |
16.0 |
15.38 |
26.0 |
|
|
|
SMA/DO-214AC |
18.90 |
20.90 |
1 |
1 |
17.0 |
14.49 |
27.6 |
|
|
|
SMA/DO-214AC |
20.00 |
22.10 |
1 |
1 |
18.0 |
13.70 |
29.2 |
|
|
|
SMA/DO-214AC |
21.10 |
23.30 |
1 |
1 |
19.0 |
13.00 |
30.8 |
|
|
|
SMA/DO-214AC |
22.20 |
24.50 |
1 |
1 |
20.0 |
12.35 |
32.4 |
|
|
|
SMA/DO-214AC |
24.40 |
26.90 |
1 |
1 |
22.0 |
11.27 |
35.5 |
|
|
|
SMA/DO-214AC |
26.70 |
29.50 |
1 |
1 |
24.0 |
10.28 |
38.9 |
|
|
|
SMA/DO-214AC |
28.90 |
31.90 |
1 |
1 |
26.0 |
9.50 |
42.1 |
|
|
|
SMA/DO-214AC |
31.10 |
34.40 |
1 |
1 |
28.0 |
8.81 |
45.4 |
|
|
|
SMA/DO-214AC |
33.30 |
36.80 |
1 |
1 |
30.0 |
8.26 |
48.4 |
|
|
|
SMA/DO-214AC |
36.70 |
40.60 |
1 |
1 |
33.0 |
7.50 |
53.3 |
|
|
|
SMA/DO-214AC |
40.00 |
44.20 |
1 |
1 |
36.0 |
6.88 |
58.1 |
|
|
|
SMA/DO-214AC |
44.40 |
49.10 |
1 |
1 |
40.0 |
6.20 |
64.5 |
|
|
|
SMA/DO-214AC |
47.80 |
52.80 |
1 |
1 |
43.0 |
5.76 |
69.4 |
|
|
|
SMA/DO-214AC |
50.00 |
55.30 |
1 |
1 |
45.0 |
5.50 |
72.7 |
|
|
|
SMA/DO-214AC |
53.30 |
58.90 |
1 |
1 |
48.0 |
5.17 |
77.4 |
|
|
|
SMA/DO-214AC |
56.70 |
62.70 |
1 |
1 |
51.0 |
4.85 |
82.4 |
|
|
|
SMA/DO-214AC |
60.00 |
66.30 |
1 |
1 |
54.0 |
4.59 |
87.1 |
|
|
|
SMA/DO-214AC |
64.40 |
71.20 |
1 |
1 |
58.0 |
4.27 |
93.6 |
|
|
|
SMA/DO-214AC |
66.70 |
73.70 |
1 |
1 |
60.0 |
4.13 |
96.8 |
|
|
|
SMA/DO-214AC |
71.10 |
78.60 |
1 |
1 |
64.0 |
3.88 |
103.0 |
|
|
|
SMA/DO-214AC |
77.80 |
86.00 |
1 |
1 |
70.0 |
3.54 |
113.0 |
|
|
|
SMA/DO-214AC |
83.30 |
92.10 |
1 |
1 |
75.0 |
3.31 |
121.0 |
|
|
|
SMA/DO-214AC |
86.70 |
95.80 |
1 |
1 |
78.0 |
3.17 |
126.0 |
|
|
|
SMA/DO-214AC |
88.80 |
97.60 |
1 |
1 |
80.0 |
3.09 |
129.6 |
|
|
|
SMA/DO-214AC |
94.40 |
104.00 |
1 |
1 |
85.0 |
2.92 |
137.0 |
|
