Φ3.2x2.7x4.5mm

Product Details

Part Number Picture Size Nominal DC Spark-over Voltage(V) Maximum impulse sparkover voltage(V) 8/20μs(KA) 10/700μs(A) Minimum insulation resistance(ΜΩ) C(pF) Download

2R75TP1

3.2×2.7×4.5mm

75±25%

550

0.5/1

4

1000

0.6

2R90TP1

3.2×2.7×4.5mm

90±20%

550

0.5/1

4

1000

0.6

2R200TP1

3.2×2.7×4.5mm

200±20%

600

0.5/1

4

1000

0.6

2R230TP1

3.2×2.7×4.5mm

230±20%

650

0.5/1

4

1000

0.6

2R350TP1

3.2×2.7×4.5mm

350±20%

900

0.5/1

4

1000

0.6

2R400TP1

3.2×2.7×4.5mm

400±20%

950

0.5/1

4

1000

0.6

2R500TP1

3.2×2.7×4.5mm

500±20%

1000

1

4

1000

0.6
