DW-NSM(L) Series

Product Details

Part Number	封装规格	IH（A）	IT(A)	Vmax(V)	Imax(A)	Ttirp current(A)	Ttirp time(s)	Pdtyp(W)	Rmin(Ω)	R1max(Ω)

DW-NSM005	1206	0.05	0.15	60	10	1.00	1.20	0.6	2.000	50.000
DW-NSM012	1206	0.125	0.29	30	20	1.00	0.20	0.6	1.500	6.000
DW-NSM016	1206	0.16	0.37	30	20	1.00	0.30	0.6	1.200	4.500
DW-NSM020	1206	0.20	0.40	16	40	8.00	0.05	0.6	0.600	2.500
DW-NSM020/24	1206	0.20	0.40	24	40	8.00	0.05	0.6	0.600	2.500
DW-NSM025/16	1206	0.25	0.50	16	40	8.00	0.08	0.6	0.550	2.300
DW-NSM025/24	1206	0.25	0.50	24	40	8.00	0.08	0.6	0.550	2.300
DW-NSM035	1206	0.35	0.75	6	40	8.00	0.10	0.6	0.300	1.200
DW-NSM035/16	1206	0.35	0.75	16	40	8.00	0.10	0.6	0.300	1.200
DW-NSM035/24	1206	0.35	0.75	24	40	8.00	0.10	0.6	0.300	1.200
DW-NSM050	1206	0.50	1.00	6	40	8.00	0.10	0.6	0.150	0.700
DW-NSM050/16	1206	0.50	1.00	16	40	8.00	0.10	0.6	0.150	0.700
DW-NSM050/24	1206	0.50	1.00	24	40	8.00	0.10	0.6	0.150	0.700
DW-NSM075	1206	0.75	1.50	6	40	8.00	0.20	0.6	0.100	0.290
DW-NSM075/8	1206	0.75	1.50	8	40	8.00	0.20	1.2	0.100	0.290
DW-NSM075/16	1206	0.75	1.50	16	40	8.00	0.20	1.2	0.100	0.290
DW-NSM090/8	1206	0.90	1.80	8	40	8.00	0.20	1.2	0.080	0.260
DW-NSM100/8	1206	1.00	2.00	8	40	8.00	0.30	1.2	0.060	0.230
DW-NSM110	1206	1.10	2.20	6	40	8.00	0.30	0.6	0.055	0.210
DW-NSM110/8	1206	1.10	2.20	8	40	8.00	0.30	1.2	0.055	0.210
DW-NSML110/8	1206	1.10	2.20	8	50	8.00	0.30	1.2	0.015	0.100
DW-NSM125/8	1206	1.25	2.50	8	40	8.00	0.40	1.2	0.050	0.180
DW-NSM150	1206	1.50	3.00	6	40	8.00	1.00	0.6	0.040	0.120
DW-NSM150/8	1206	1.50	3.00	8	40	8.00	1.00	1.2	0.040	0.120
DW-NSML150	1206	1.50	3.00	6	50	8.00	5.00	1.2	0.010	0.065
DW-NSML150/8	1206	1.50	3.00	8	50	8.00	5.00	1.2	0.010	0.065
DW-NSML150/12	1206	1.50	3.00	12	50	8.00	5.00	1.2	0.010	0.065
DW-NSML175	1206	1.75	3.50	6	50	8.00	5.00	1.2	0.010	0.060
DW-NSM175/8	1206	1.75	3.50	8	40	8.00	5.00	1.2	0.010	0.060
DW-NSML175/12	1206	1.75	3.50	12	40	8.00	5.00	1.2	0.010	0.060
DW-NSM200/8	1206	2.00	4.00	8	40	8.00	5.00	1.2	0.008	0.040
DW-NSML200	1206	2.00	4.00	6	50	8.00	5.00	1.2	0.008	0.040
DW-NSML200/8	1206	2.00	4.00	8	50	8.00	5.00	1.2	0.008	0.040
DW-NSML200/12	1206	2.00	4.00	12	50	8.00	5.00	1.2	0.008	0.040
DW-NSML260	1206	2.60	5.20	6	50	8.00	5.00	1.2	0.004	0.025
DW-NSML260/12	1206	2.60	5.20	12	50	8.00	5.00	1.2	0.004	0.025
DW-NSML300	1206	3.00	6.00	6	50	8.00	5.00	1.5	0.004	0.020
DW-NSML300/12	1206	3.00	6.00	12	50	8.00	5.00	1.5	0.004	0.020
DW-NSML350	1206	3.50	7.00	6	50	8.00	5.00	1.5	0.004	0.018
DW-NSML350/12	1206	3.50	7.00	12	50	8.00	5.00	1.5	0.004	0.018
DW-NSML380	1206	3.80	7.60	6	50	8.00	5.00	1.5	0.004	0.016
DW-NSML380/12	1206	3.80	7.60	12	50	8.00	5.00	1.5	0.004	0.016
DW-NSML400	1206	4.00	8.00	6	50	8.00	5.00	1.5	0.004	0.014
DW-NSML400/12	1206	4.00	8.00	12	50	8.00	5.00	1.5	0.004	0.014
DW-NSML450	1206	4.50	9.00	6	50	22.50	5.00	1.5	0.002	0.012
DW-NSML450/12	1206	4.50	9.00	12	50	22.50	5.00	1.5	0.002	0.012
DW-NSML500	1206	5.00	10.00	6	50	25.00	5.00	1.5	0.002	0.011
DW-NSML550	1206	5.50	11.00	6	50	27.50	5.00	1.5	0.002	0.010
DW-NSML600	1206	6.00	12.00	6	50	30.00	5.00	1.5	0.002	0.009
DW-NSML650	1206	6.50	13.00	6	50	32.50	5.00	1.5	0.001	0.009
DW-NSML700	1206	7.00	14.00	6	50	35.00	5.00	1.5	0.001	0.008
