• Glass passivated chip
• 1500 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate (duty
cycle):0.01 %
• Uni and Bidirectional unit
• Low leakage
• Excellent clamping capability
• Very fast response time
• RoHS compliant
| Part Number | Picture | Encapsulation | VBR.MIN(V) | VBR.MAX(V) | IT(mA) | IR(μA) | VRWM(V) | IPP(A) | VC(V) | Download |
|---|---|---|---|---|---|---|---|---|---|---|
|
SMC/DO-214AB |
6.46 |
7.14 |
10 |
1000 |
5.8 |
142.86 |
10.5 |
|
|
|
SMC/DO-214AB |
7.13 |
7.88 |
10 |
500 |
6.4 |
132.74 |
11.3 |
|
|
|
SMC/DO-214AB |
7.79 |
8.61 |
10 |
200 |
7.0 |
123.97 |
12.1 |
|
|
|
SMC/DO-214AB |
8.65 |
9.56 |
1 |
50 |
7.8 |
111.94 |
13.4 |
|
|
|
SMC/DO-214AB |
9.50 |
10.50 |
1 |
10 |
8.6 |
103.45 |
14.5 |
|
|
|
SMC/DO-214AB |
10.45 |
11.55 |
1 |
5 |
9.4 |
96.15 |
15.6 |
|
|
|
SMC/DO-214AB |
11.40 |
12.60 |
1 |
5 |
10.2 |
89.82 |
16.7 |
|
|
|
SMC/DO-214AB |
12.35 |
13.65 |
1 |
1 |
11.1 |
82.42 |
18.2 |
|
|
|
SMC/DO-214AB |
14.25 |
15.75 |
1 |
1 |
12.8 |
70.75 |
21.2 |
|
|
|
SMC/DO-214AB |
15.20 |
16.80 |
1 |
1 |
13.60 |
66.67 |
22.5 |
|
|
|
SMC/DO-214AB |
17.10 |
18.90 |
1 |
1 |
15.3 |
59.52 |
25.2 |
|
|
|
SMC/DO-214AB |
19.00 |
21.00 |
1 |
1 |
17.1 |
54.15 |
27.7 |
|
|
|
SMC/DO-214AB |
20.90 |
23.10 |
1 |
1 |
18.8 |
49.02 |
30.6 |
|
|
|
SMC/DO-214AB |
22.80 |
25.20 |
1 |
1 |
20.5 |
45.18 |
33.2 |
|
|
|
SMC/DO-214AB |
25.65 |
28.35 |
1 |
1 |
23.1 |
40.00 |
37.5 |
|
|
|
SMC/DO-214AB |
28.50 |
31.50 |
1 |
1 |
25.6 |
36.23 |
41.4 |
|
|
|
SMC/DO-214AB |
31.35 |
34.65 |
1 |
1 |
28.2 |
32.82 |
45.7 |
|
|
|
SMC/DO-214AB |
34.20 |
37.80 |
1 |
1 |
30.8 |
30.06 |
49.9 |
|
|
|
SMC/DO-214AB |
37.05 |
40.95 |
1 |
1 |
33.3 |
27.83 |
53.9 |
|
|
|
SMC/DO-214AB |
40.85 |
45.15 |
1 |
1 |
36.8 |
25.30 |
59.3 |
|
|
|
SMC/DO-214AB |
44.65 |
49.35 |
1 |
1 |
40.2 |
23.15 |
64.8 |
|
|
|
SMC/DO-214AB |
48.45 |
53.55 |
1 |
1 |
43.6 |
21.40 |
70.1 |
|
|
|
SMC/DO-214AB |
53.20 |
58.80 |
1 |
1 |
47.8 |
19.48 |
77.0 |
|
|
|
SMC/DO-214AB |
58.90 |
65.10 |
1 |
1 |
53.0 |
17.65 |
85.0 |
|
|
|
SMC/DO-214AB |
64.60 |
71.40 |
1 |
1 |
58.1 |
16.30 |
92.0 |
|
|
|
SMC/DO-214AB |
71.25 |
78.75 |
1 |
1 |
64.1 |
14.56 |
103.0 |
|
|
|
SMC/DO-214AB |
77.90 |
86.10 |
1 |
1 |
70.1 |
13.27 |
113.0 |
|
|
|
SMC/DO-214AB |
86.45 |
195.55 |
1 |
1 |
77.8 |
12.00 |
125.0 |
|
|
|
SMC/DO-214AB |
95.00 |
105.00 |
1 |
1 |
85.5 |
10.95 |
137.0 |
|
|
|
SMC/DO-214AB |
104.50 |
115.50 |
1 |
1 |
94.0 |
9.87 |
152.0 |
|
|
|
SMC/DO-214AB |
114.00 |
126.00 |
1 |
1 |
102.0 |
9.09 |
165.0 |
|
|
|
SMC/DO-214AB |
123.50 |
136.50 |
1 |
1 |
111.0 |
8.38 |
179.0 |
|
|
|
SMC/DO-214AB |
142.50 |
157.50 |
1 |
1 |
128.0 |
7.25 |
207.0 |
|
|
|
SMC/DO-214AB |
152.00 |
168.00 |
1 |
1 |
136.0 |
6.85 |
219.0 |
|
|
|
SMC/DO-214AB |
161.50 |
178.50 |
1 |
1 |
145.0 |
6.41 |
234.0 |
|
|
|
SMC/DO-214AB |
171.00 |
189.00 |
1 |
1 |
154.0 |
6.10 |
246.0 |
|
|
|
SMC/DO-214AB |
190.00 |
210.00 |
1 |
1 |
171.0 |
5.47 |
274.0 |
|
|
|
SMC/DO-214AB |
209.00 |
231.00 |
1 |
1 |
185.0 |
4.57 |
328.0 |
|
|
|
SMC/DO-214AB |
237.50 |
262.50 |
1 |
1 |
214.0 |
4.36 |
344.0 |
|
|
|
SMC/DO-214AB |
285.00 |
315.00 |
1 |
1 |
256.0 |
3.62 |
414.0 |
|
|
|
SMC/DO-214AB |
332.50 |
367.50 |
1 |
1 |
299.3 |
3.11 |
482.0 |
|
|
|
SMC/DO-214AB |
361.00 |
399.00 |
1 |
1 |
324.9 |
2.86 |
524.4 |
|
|
|
SMC/DO-214AB |
380.00 |
420.00 |
1 |
1 |
342.0 |
2.72 |
548.0 |
|
|
|
SMC/DO-214AB |
418.00 |
462.00 |
1 |
1 |
376.2 |
2.47 |
602.0 |
|
|
|
SMC/DO-214AB |
475.00 |
525.00 |
1 |
1 |
427.5 |
2.17 |
690.0 |
|
|
|
SMC/DO-214AB |
494.00 |
546.00 |
1 |
1 |
444.6 |
2.09 |
717.6 |
|
|
|
SMC/DO-214AB |
522.50 |
577.50 |
1 |
1 |
470.3 |
1.98 |
759.0 |
|
|
|
SMC/DO-214AB |
570.00 |
630.00 |
1 |
1 |
513.0 |
1.81 |
828.00 |
|
