SMBJ Series

Encapsulation: SMB/DO-214AA
Ppp: 600W
Vrwm: 5.0 V-440.0 V
Ipp: 0.84 A-62.50 A
Response Time: <1.0PS

Product Details

• Glass passivated chip

• 600 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate (duty

cycle):0.01 %

• Low leakage
• Uni and Bidirectional unit
• Excellent clamping capability
• Very fast response time
• RoHS compliant

Part Number Picture Encapsulation VBR.MIN(V) VBR.MAX(V) IT(mA) IR(μA) VRWM(V) IPP(A) VC(V) Download

SMBJ5.0A/SMBJ5.0CA

SMB/DO-214AA

6.40

7.00

10

800

5.0

65.22

9.2

SMBJ8.0A/SMBJ8.0CA

SMB/DO-214AA

8.89

9.83

1

50

8.0

44.12

13.6

SMBJ7.5A/SMBJ7.5CA

SMB/DO-214AA

8.33

9.21

1

100

7.5

46.51

12.9

SMBJ7.0A/SMBJ7.0CA

SMB/DO-214AA

7.78

8.60

10

200

7.0

50.00

12.0

SMBJ6.5A/SMBJ6.5CA

SMB/DO-214AA

7.22

7.98

10

500

6.5

53.57

11.2

SMBJ6.0A/SMBJ6.0CA

SMB/DO-214AA

6.67

7.37

10

800

6.0

58.25

10.3

SMBJ8.5A/SMBJ8.5CA

SMB/DO-214AA

9.44

10.40

1

10

8.5

41.67

14.4

SMBJ11A/SMBJ11CA

SMB/DO-214AA

12.20

13.50

1

1

11.0

32.97

18.2

SMBJ9.0A/SMBJ9.0CA

SMB/DO-214AA

10.00

11.10

1

5

9.0

38.96

15.4

SMBJ10A/SMBJ10CA

SMB/DO-214AA

11.10

12.30

1

5

10.0

35.29

17.0

SMBJ12A/SMBJ12CA

SMB/DO-214AA

13.30

14.70

1

1

12.0

30.15

19.9

SMBJ13A/SMBJ13CA

SMB/DO-214AA

14.40

15.90

1

1

13.0

27.91

21.5

SMBJ14A/SMBJ14CA

SMB/DO-214AA

15.60

17.20

1

1

14.0

25.86

23.2

SMBJ17A/SMBJ17CA

SMB/DO-214AA

18.90

20.90

1

1

17.0

21.74

27.6

SMBJ15A/SMBJ15CA

SMB/DO-214AA

16.70

18.50

1

1

15.0

24.59

24.4

SMBJ16A/SMBJ16CA

SMB/DO-214AA

17.80

19.70

1

1

16.0

23.08

26.0

SMBJ18A/SMBJ18CA

SMB/DO-214AA

20.00

22.10

1

1

18.0

20.55

29.2

SMBJ19A/SMBJ19CA

SMB/DO-214AA

21.10

23.30

1

1

19.0

19.49

30.8

SMBJ20A/SMBJ20CA

SMB/DO-214AA

22.20

24.50

1

1

20.0

18.52

32.4

SMBJ24A/SMBJ24CA

SMB/DO-214AA

26.70

29.50

1

1

24.0

15.42

38.9

SMBJ22A/SMBJ22CA

SMB/DO-214AA

24.40

26.90

1

1

22.0

16.90

35.5

SMBJ26A/SMBJ26CA

SMB/DO-214AA

28.90

31.90

1

1

26.0

14.25

42.1

SMBJ30A/SMBJ30CA

SMB/DO-214AA

33.30

36.80

1

1

30.0

12.40

48.4

SMBJ28A/SMBJ28CA

SMB/DO-214AA

31.10

34.40

1

1

28.0

13.22

45.4

SMBJ33A/SMBJ33CA

SMB/DO-214AA

36.70

40.60

1

1

33.0

11.26

53.3

SMBJ36A/SMBJ36CA

SMB/DO-214AA

40.00

44.20

1

1

36.0

10.33

58.1

SMBJ40A/SMBJ40CA

SMB/DO-214AA

44.40

49.10

1

1

40.0

9.30

64.5

SMBJ43A/SMBJ43CA

SMB/DO-214AA

47.80

52.80

1

1

43.0

8.65

69.4

SMBJ45A/SMBJ45CA

SMB/DO-214AA

50.00

55.30

1

1

45.0

8.25

72.7

SMBJ48A/SMBJ48CA

SMB/DO-214AA

53.30

58.90

1

1

48.0

7.75

77.4

SMBJ51A/SMBJ51CA

SMB/DO-214AA

56.70

62.70

1

1

51.0

7.28

82.4

SMBJ54A/SMBJ54CA

SMB/DO-214AA

60.00

66.30

1

1

54.0

6.89

87.1

SMBJ58A/SMBJ58CA

SMB/DO-214AA

64.40

71.20

1

1

58.0

6.41

93.6

SMBJ60A/SMBJ60CA

SMB/DO-214AA

66.70

73.70

1

1

60.0

6.20

96.8

SMBJ64A/SMBJ64CA

SMB/DO-214AA

71.10

78.60

1

1

64.0

5.83

103.0

SMBJ70A/SMBJ70CA

SMB/DO-214AA

77.80

86.00

1

1

70.0

5.31

113.0

SMBJ75A/SMBJ75CA

SMB/DO-214AA

83.30

92.10

1

1

75.0

4.96

121.0

SMBJ78A/SMBJ78CA

SMB/DO-214AA

86.70

95.80

1

1

78.0

4.76

126.0

SMBJ80A/SMBJ80CA

SMB/DO-214AA

88.80

97.60

1

1

80.0

4.63

129.6

SMBJ85A/SMBJ85CA

SMB/DO-214AA

94.40

104.00

1

1

85.0

4.38

137.0

SMBJ90A/SMBJ90CA

SMB/DO-214AA

100.00

111.00

1

1

90.0

4.11

146.0

SMBJ100A/SMBJ100CA

SMB/DO-214AA

111.00

123.00

1

1

100.0

3.70

162.0

SMBJ110A/SMBJ110CA

SMB/DO-214AA

122.00

135.00

1

1

110.0

3.39

177.0

SMBJ120A/SMBJ120CA

SMB/DO-214AA

133.00

147.00

1

1

120.0

3.11

193.0

SMBJ130A/SMBJ130CA

SMB/DO-214AA

144.00

159.00

1

1

130.0

2.87

209.0

SMBJ140A/SMBJ140CA

SMB/DO-214AA

155.00

171.00

1

1

140.0

2.65

226.8

SMBJ150A/SMBJ150CA

SMB/DO-214AA

167.00

185.00

1

1

150.0

2.47

243.0

SMBJ160A/SMBJ160CA

SMB/DO-214AA

178.00

197.00

1

1

160.0

2.32

259.0

SMBJ170A/SMBJ170CA

SMB/DO-214AA

189.00

209.00

1

1

170.0

2.18

275.0

SMBJ180A/SMBJ180CA

SMB/DO-214AA

200.00

220.00

1

1

180.0

2.06

291.6

SMBJ190A/SMBJ190CA

SMB/DO-214AA

211.00

232.00

1

1

190.0

1.95

307.8

SMBJ200A/SMBJ200CA

SMB/DO-214AA

224.00

247.00

1

1

200.0

1.85

324.0

SMBJ220A/SMBJ220CA

SMB/DO-214AA

246.00

272.00

1

1

220.0

1.69

356.0

SMBJ250A/SMBJ250CA

SMB/DO-214AA

279.00

309.00

1

1

250.0

1.48

405.0

SMBJ300A/SMBJ300CA

SMB/DO-214AA

335.00

371.00

1

1

300.0

1.23

486.0

SMBJ350A/SMBJ350CA

SMB/DO-214AA

391.00

432.00

1

1

350.0

1.06

567.0

SMBJ400A/SMBJ400CA

SMB/DO-214AA

447.00

494.00

1

1

400.0

0.93

648.0

SMBJ440A/SMBJ440CA

SMB/DO-214AA

492.00

543.00

1

1

440.0

0.84

713.0
