• Optimized glass passivated chip
• TJ = 175 °C capability suitable for high reliability and automotive requirement
• 4600 W peak pulse power capability with a 10/1000 μs waveform, repetitive rate (duty
cycle):0.01 %
• Meet ISO 7637-2 5a/5b and ISO 16750 load dump test (varied by test condition)
• AEC-Q101 qualified
• Low leakage current
• Low forward voltage drop
• Uni-directional polarity
• Excellent clamping capability
• Very fast response time
• RoHS compliant
| Part Number | Picture | Encapsulation | VBR.MIN(V) | VBR.MAX(V) | IT(mA) | IR(μA) | VRWM(V) | IPP(A) | VC(V) | Download |
|---|---|---|---|---|---|---|---|---|---|---|
|
DO-218AB |
11.1 |
12.3 |
2.0 |
15 |
10 |
271 |
17.0 |
|
|
|
DO-218AB |
12.2 |
13.5 |
5.0 |
10 |
11 |
253 |
18.2 |
|
|
|
DO-218AB |
13.3 |
14.7 |
5.0 |
10 |
12 |
231 |
19.9 |
|
|
|
DO-218AB |
14.4 |
15.9 |
5.0 |
10 |
13 |
214 |
21.5 |
|
|
|
DO-218AB |
15.6 |
17.2 |
5.0 |
10 |
14 |
198 |
23.2 |
|
|
|
DO-218AB |
16.7 |
18.5 |
5.0 |
10 |
15 |
189 |
24.4 |
|
|
|
DO-218AB |
17.8 |
19.7 |
5.0 |
10 |
16 |
177 |
26.0 |
|
|
|
DO-218AB |
18.9 |
20.9 |
5.0 |
10 |
17 |
167 |
27.6 |
|
|
|
DO-218AB |
20.0 |
22.1 |
5.0 |
10 |
18 |
158 |
29.2 |
|
|
|
DO-218AB |
22.2 |
24.5 |
5.0 |
10 |
20 |
142 |
32.4 |
|
|
|
DO-218AB |
24.4 |
26.9 |
5.0 |
10 |
22 |
130 |
35.5 |
|
|
|
DO-218AB |
26.7 |
29.5 |
5.0 |
10 |
24 |
118 |
38.9 |
|
|
|
DO-218AB |
28.9 |
31.9 |
5.0 |
10 |
26 |
109 |
42.1 |
|
|
|
DO-218AB |
31.1 |
34.4 |
5.0 |
10 |
28 |
101 |
45.4 |
|
|
|
DO-218AB |
33.3 |
36.8 |
5.0 |
10 |
30 |
95 |
48.4 |
|
|
|
DO-218AB |
36.7 |
40.6 |
5.0 |
10 |
33 |
86 |
53.3 |
|
|
|
DO-218AB |
40.0 |
44.2 |
5.0 |
10 |
36 |
79 |
58.1 |
|
|
|
DO-218AB |
44.4 |
49.1 |
5.0 |
10 |
40 |
71 |
64.5 |
|
|
|
DO-218AB |
47.8 |
52.8 |
5.0 |
10 |
43 |
66 |
69.4 |
|
